Ultra Pulley Attachment

This Class 2 (<1 mW) laser pointer can be used with a Vernier Photogate or Go Direct® Photogate to produce a gate that is wider than the normal 7.5 cm spacing, making it possible to measure the speed of an automobile or of a person running. The laser case is made of aluminum, and it uses two AAA batteries (included). The wavelength of the light is 650 nm. A momentary switch (normally off) controls the laser beam. User Manual - LASER

Picket Fences have eight opaque bars spaced every 5 cm, silk-screened directly onto clear plastic. Drop the picket fence through a photogate to obtain records of position, velocity and acceleration vs time or to measure g. User Manual - PF

The Pulley Bracket attaches an Ultra Pulley to the end of a Vernier Dynamics Cart and Track System. The bracket includes an attachment for a photogate as well. What's included Track attachment with slot Photogate attachment Long bolt, 39 mm Short bolt, 23.4 mm User Manual - B-SPA

The Rotary Motion Sensor and Rotational Motion Accessory Kit can be used to study rotational inertia, conservation of angular momentum, and additional experiments. Specifications Resolution: 1° or 0.25° Optical Encoder: Bidirectional, quadrature encoder Maximum Speed: 30 rev/s at 1° resolution 7.5 rev/s at 0.25° resolution 3-step Pulley: 10 mm, 29 mm, and 48 mm groove diameter Accuracy: ≤±1.0％ FS What's included Rotary Motion Sensor with Accessory Kit includes Rotary Motion SensorThumb screw 3-step pulley and mounting screw O-ring Rotational Motion Accessory Kit2 3-1/2 inch diameter, 1/4 inch thick solid aluminum disks 1 steel disk with 1-1/8 inch central hole 1 plastic hub to hold the steel disk on the 3-step pulley 1 15 inch hollow aluminum rod 1 Ultra Pulley Ultra Pulley Swivel Mount, which allows the pulley to be mounted on the Go Direct® Rotary Motion Sensor 2 Masses with locking screws Rotary Motion Sensor (sensor only) includes Thumb screw 3-step pulley and mounting screw O-ring WARNING: This product can expose you to chemicals, including chromium, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, see www.P65Warnings.ca.gov User Manual - RMPK-BTD

Use the Photogate to study free fall, rolling objects, collisions, and pendulums. Specifications Power req: 5 VDC at 40 mA Infrared source: Peak at 880 nm Dimension: 75 mm gate width Output is high and LED off for unblocked gate Output is low and LED on for blocked gate Beam approximately 9 mm from the end of the gate arms Resolution: 1μs What's included Vernier Photogate (1) Interface cable (1) Accessory rod User Manual - VPG-BTD

This light-weight tripod is a perfect support for the Laser Pointer or any other laser pointer, which has a 7/16-inch (1.1 cm) outside diameter. A pair of clips attached to the pivoting bracket securely holds the laser in place. This assembly allows you to accurately point the laser at a photogate. User Manual - STAND

The Dynamics Cart and Track System provides students with the tools they need to explore kinematics, dynamics, momentum, and energy. This versatile system can also be easily adapted to study optics, color, and diffraction. The Dynamics and Track System is ideal for studying Newton's second law, acceleration on an inclined plane, conservation of momentum, and much more. This traditional cart and track system features an aluminum track, two low-friction, plastic carts, an ultra pulley, and all of the necessary attachment accessories. Easily attach sensors (sold separately) to carts or to the track for data collection, like a Motion Detector, Dual-Range Force Sensor, Wireless Dynamics Sensor System, Photogate, or an Accelerometer. Add the Vernier Optics Expansion Kit (OEK) and use the track as an optics bench. The Dynamics Cart and Track Sytem includes: Combination 1.2 m Track/Optics Bench Standard Cart with magnetic and hook-and-pile end caps Plunger Cart with magnetic and hook-and-pile end caps 4 hexagonal masses, 125 g each Mounting hardware for Dual-Range Force Sensor and accelerometers Adjustable End Stop 2 Adjustable Two-Foot Levelers Motion Detector Bracket Motion Detector Reflector Flag Rod Clamp 2 Photogate Brackets Ultra Pulley Pulley Bracket User manual The long-track version includes the same carts and accessories as the Dynamics Cart and Track System but substitutes a 2.2m Track for the 1.2m Track.   Shipping costs standard version: The standard version 1.2m is sent as PostPac Economy bulky goods. The total shipping costs are CHF 31.00.   Shipping costs long version:   The long track version 2.2m is shipped by freight forwarding. The costs for shipping amount to a total of CHF 74.00.

This completely wireless system simplifies experiment setup and allows basic experiments to be conducted with or without the track. Description The Dynamics Cart and Track System with Go Direct Sensor Cart includes essential laboratory equipment for teaching dynamics and kinematics. Using our Go Direct Sensor Cart, students can explore force, position, velocity, and acceleration directly on their Bluetooth®-enabled device—no wires or additional equipment required. Each cart features built-in sensors to simplify experiment setup and allow experiments to be conducted on or off the track. Specifications Position resolution: 0.25 mm, reported by default at 1 mm steps Force range: ±50 N Accelerometer range: ±160 m/s2 Track length: 1.2 m Shipping costs standard version: The standard version 1.2m is sent as PostPac Economy bulky goods. The total shipping costs are CHF 31.00.   Shipping costs long version: The long track version 2.2m is shipped by freight forwarding. The costs for shipping amount to a total of CHF 74.00.
